Shiny-Control Technology Develop (Beijing) Co., Ltd. 86-010-69458834 makabaka@shiny-control.cn
Multiple Transceiver Channels UAV Surveillance Radar Safeguarding Border Security Radar

Multiple Transceiver Channels UAV Surveillance Radar Safeguarding Border Security Radar

  • Highlight

    Multiple Transceiver Channels Security Radar

    ,

    Safeguarding Border UAV Surveillance Radar

  • Model NO.
    RS1500A
  • Installation Mode
    Ground Steel Bracket Or Tripod
  • Application
    Industry, Special Equipment
  • External Interfaces
    Rj-45
  • Power Consumption
    ≤30W
  • Transport Package
    Aviation Box Packaging
  • Specification
    X Band
  • Trademark
    OME Acceptable
  • Origin
    China
  • HS Code
    8526109090
  • Supply Ability
    100pieces/Year
  • Customization
    Available
  • Type
    Sensor
  • Usage
    Security Warning And Protection
  • Place of Origin
    China
  • Brand Name
    OEM
  • Certification
    ISO
  • Minimum Order Quantity
    10

Multiple Transceiver Channels UAV Surveillance Radar Safeguarding Border Security Radar

Surveillance Radar Sensor with External Interfaces Rj-45 Security Warning and Protection



Basic Information


Our RS1500A radar products are meticulously engineered to detect dynamic targets - be it individuals, vehicles, or maritime vessels - within the observation field. This cutting-edge device reliably reports vital data about the target's distance, azimuth, and velocity, even for multiple targets simultaneously. By utilizing this precise data, the radar seamlessly integrates with cameras and optoelectronic systems to track, position, identify, and document events, offering unparalleled surveillance capabilities.

Radar technology is a proactive solution applicable in diverse environments - from smart shipping and fishery protection to bridge collision prevention and vessel traffic monitoring. It serves as a robust tool for the security of critical infrastructure, including substations, detention centers, and oil pipelines. The radar is indispensable for airport perimeter security, railway safety, highway traffic control, and more. With superior performance, competitive pricing, and open interfaces, our radar sensor is effortlessly compatible with cameras, infrared, and other devices, making it a versatile choice for intelligent surveillance.



Model NO. RS1500A
Operating frequency 24GHz-24.25GHz
Swept bandwidth 30MHZ
Data rate 3HZ
Azimuth scan range ±45°
Pitch coverage 15°
Maximum number of objects that can be detected 100
Maximum Detection Range 1.3km (Pedestrians) ≥ 2.4km (Vehicle/Ships)
Minimum travel distance ≤5m
Target velocity range 0.5m/s~35m/s(1.8km/h~126km/h)
Packaging & Deliver
weight ≤5kg
Structural dimensions 350mm*350mm*55mm

Ingress protection IP66
Multiple Transceiver Channels UAV Surveillance Radar Safeguarding Border Security Radar 0
Radar Working DiagramMultiple Transceiver Channels UAV Surveillance Radar Safeguarding Border Security Radar 1


Multiple Transceiver Channels UAV Surveillance Radar Safeguarding Border Security Radar 2



Multiple Transceiver Channels UAV Surveillance Radar Safeguarding Border Security Radar 3Multiple Transceiver Channels UAV Surveillance Radar Safeguarding Border Security Radar 4





Features

Primarily designed for safeguarding borders and high-security areas, this advanced radar monitors personnel, vehicles, ships, and other targets with distinct features:

Multiple Transceiver Channels: Equipped with 3 transmitters and 32 receivers, this Frequency Modulated Continuous Wave (FMCW) radar boasts a phased array system, ensuring comprehensive and precise surveillance.
High Detection Power: Capable of detecting pedestrians at distances exceeding 1,000 meters, and vehicles and boats beyond 2,000 meters, this radar offers exceptional reach.

High Measurement Accuracy: Achieving an angular measurement accuracy of up to 0.3°, and a ranging accuracy of 2 meters, this device guarantees precision.
   Our radar supports multiple operating frequency bands, adeptly avoiding co-channel interference for uninterrupted performance.

   It facilitates the demarcation of defense zones, effectively filtering out false alarms from outside the core area, ensuring focused security.

   Utilizing sophisticated machine learning algorithms, it aids in the identification and resolution of varying target sizes, allowing customers to conduct targeted screenings with ease.
