| Model NO. | RST8000 |
| Operating frequency | Ku Band |
| Detection range and scanning mode | Azimuth: 360° mechanical scanning; Pitch phase sweep range: ≥30° |
| Peak transmit power | ≤700W |
| Detection range | Drone DJI spirit 3, 4, Pd=85% |
| Maximum detection range | ≥8.5km |
| Minimum detection range | ≤300m |
| Minimum detection speed | ≤2m/s |
| Precision of coordinate measurement (root mean square error) | Distance accuracy: ≤10m Azimuth accuracy: ≤0.4° Pitch accuracy: ≤0.3° |
| Data refresh rate | 360° |
| Weekly data refresh rate | 3s |
| weight(Radar, PTZ, tripod) | ≤45kg |
| Structural dimensions | ≤600mm*500mm*100mm |
| Power supply | AC220V/50Hz |
(1) In 360° global surveillance mode, the radar servo scans the entire airspace of the target at a constant speed of 360° according to the set rate, finds aerial targets such as drones, tracks and builds the target, measures the target's distance, Angle, altitude, speed and other detailed information, and reports the terminal charge in time.
(2) The radar output can guide the photoelectric system and other systems for identification, confirmation and disposal.
(3) With independent search and automatic search tracking conversion capabilities, conventional background environment, can achieve automatic unattended;
(4) Light and portable, fast mobile deployment, vehicle application.
(5) Wide airspace coverage, flexible application deployment azimuth maximum coverage 360° range, pitch maximum coverage 30° range, 360° cycle scan application, sector focus monitoring application deployment.
1) 360° Global Low Altitude Monitoring, Detection, and Tracking Function:
In the 360° global monitoring mode, our radar servo performs a meticulous sweep across the entire airspace at an unwavering speed of 360°. It diligently detects airborne targets like drones and balloons, ensuring they're tracked and navigated with precision. This sophisticated system measures intricate details such as distance, angle, altitude, and velocity, swiftly relaying this crucial data to the command terminal for immediate action.
2) Single Target Tracking: Once the radar locks onto a target, it seamlessly transitions into a tracking mode, delivering ultra-precise tracking of your target of interest with a rapid data rate of merely 1 second.
3) The radar's output empowers the guidance for identification, confirmation, and strategic handling of optoelectronic systems and other integrated systems.
